The CTCL-1.5" belongs to the CTCL — Custom Trunnion Cross Lug series: a welded-body, double-acting hydraulic cylinder with a 1.5-inch (38.1 mm) bore, rated at 3,000 PSI (207 bar).

CTCL = Custom Trunnion Cross Lug. Mounting design:

• Mid-body: Trunnion — a pair of coaxial pivot pins welded to the cylinder barrel at its center of gravity, allowing the entire cylinder to pivot on a fixed support bracket. This is the primary mounting point.
• Rear (cap end): Cross lug — symmetrical dual-lug brackets at the cap end providing a secondary fixed anchor point.
• Front (rod end): Threaded rod end — externally threaded piston rod for adjustable front connection length and angle.

The trunnion mid-mount allows the cylinder to swing through an arc during operation, making the CTCL series ideal for large-scale equipment where the cylinder must pivot at its center rather than at its ends. Available in 16 standard stroke lengths from 4" to 36", including an ASAE-standard configuration.

Technical Specifications

• Series: CTCL — Custom Trunnion Cross Lug
• Bore Diameter: 1.5 in (38.1 mm)
• Working Pressure: 3,000 PSI (207 bar)
• Action: Double-acting
• Body: Welded construction
• Mid-body Mount: Trunnion (coaxial pivot pins at barrel center)
• Rear Connection: Cross lug (fixed symmetrical dual-lug)
• Front Connection: Threaded rod end (adjustable length)
• Standard Strokes: 4", 6", 8", 8" (ASAE), 10", 12", 14", 16", 18", 20", 24", 28", 30", 32", 34", 36"
• Model Numbers: CTCL-1504 | CTCL-1506 | CTCL-1508 | CTCL-1508-ASAE | CTCL-1510 | CTCL-1512 | CTCL-1514 | CTCL-1516 | CTCL-1518 | CTCL-1520 | CTCL-1524 | CTCL-1528 | CTCL-1530 | CTCL-1532 | CTCL-1534 | CTCL-1536
• Origin: China | HS Code: 841221

CTCL Series — Full Bore Range

• CTCL-1.5": 38.1 mm — 16 standard strokes incl. ASAE
• CTCL-2": 50.8 mm | CTCL-2.5": 63.5 mm | CTCL-3": 76.2 mm
• CTCL-3.5": 88.9 mm | CTCL-4": 101.6 mm

Applications

• Large-scale agricultural machinery requiring mid-body pivot mounting
• Construction equipment with center-pivot cylinder installations
• Industrial presses and heavy clamping systems
• Special OEM equipment where end-mount cylinders cannot be used
• ASAE-compatible agricultural tractor hydraulic systems

FAQ

Q: What does CTCL stand for?
A: CTCL = Custom Trunnion Cross Lug. Welded body with mid-body trunnion pivot mount, cross-lug cap end anchor, and threaded rod end.

Q: What is a trunnion mount?
A: A trunnion is a pair of coaxial pins welded to the cylinder barrel, allowing the entire cylinder to pivot on a fixed support bracket at its center of gravity. This is the primary mounting method for the CTCL series.

Q: Is it double-acting?
A: Yes. All CTCL cylinders are double-acting.

Q: What does the ASAE model mean?
A: CTCL-1508-ASAE is dimensionally compatible with ASAE-standard agricultural tractor hydraulic systems for direct bolt-on replacement.

Q: What are the shipping terms?
A: FOB. Shipping costs, duties, and clearance fees are the buyer's responsibility.

Why Choose CTCL-1.5" for OEM?

• Trunnion mid-body mount — center-pivot for large-scale equipment
• Cross lug rear anchor — fixed, high-strength secondary mount
• Threaded rod end — adjustable front connection length
• Welded body — compact, 3,000 PSI rated, double-acting
• 16 standard strokes incl. ASAE configuration
• Full OEM/ODM support | Volume pricing available

Manufactured by Customized Hydraulic Co., Ltd — CHC/Custom hydraulic cylinder OEM specialists serving the US, Canada, UK, and EU markets.

📋 Need a custom bore, stroke, or mounting? Submit a Quote Request →

📄 Product Spec Sheet: Coming soon — contact us for full technical documentation.

OEM & Bulk Order Information

• Quality Certification: ISO 9001 Certified — CUSTOM Hydraulic Machinery Co., Ltd (Wuxi, China)
• Manufacturer: CUSTOM Hydraulic Machinery Co., Ltd (Fuxin, China)
• MOQ: 1 unit (sample order) | 10 units minimum per bore size (bulk)
• Lead Time: 7–15 business days (standard) | Rush orders available upon request
• Custom Options: Bore diameter, stroke length, port size, rod diameter & mounting style — all customizable for OEM requirements
• OEM/ODM: Private label & custom branding available
• Shipping Terms: FOB Fuxin, China | DDP available for qualified buyers
