CTR3-2.5" Tie-Rod 3000PSI Hydraulic Cylinder | CHC OEM

CTR3-2.5" | Custom Tie-Rod 3000PSI Hydraulic Cylinder | OEM Ready

The CTR3-2.5" belongs to the CTR3 — Custom Tie-Rod 3000PSI series: a tie-rod body, double-acting hydraulic cylinder with a 2.5-inch (63.5 mm) bore, rated at 3,000 PSI (207 bar).

CTR3 = Custom Tie-Rod 3000PSI. Key features:

Tie-rod construction: Both end caps secured by external tie rods — complete field disassembly for seal replacement without special tools.
Rear (cap end): Tie-rod rear connection.
Front (rod end): Double-lug front clevis + threaded rod end for adjustable connection length.

Technical Specifications

Series: CTR3 — Custom Tie-Rod 3000PSI
Bore Diameter: 2.5 in (63.5 mm)
Working Pressure: 3,000 PSI (207 bar)
Action: Double-acting
Body: Tie-rod construction (field-serviceable)
Rear Connection: Tie-rod rear
Front Connection: Double-lug front clevis + threaded rod end
Origin: China | HS Code: 841221

CTR3 Series — Full Bore Range

CTR3-2": 50.8 mm | CTR3-2.5": 63.5 mm | CTR3-3": 76.2 mm
CTR3-3.5": 88.9 mm | CTR3-4": 101.6 mm | CTR3-5": 127 mm

Applications

Agricultural machinery: tractors, loaders, plows, balers
Construction equipment and attachments
Industrial presses and clamping systems
Retrofit and replacement applications requiring field-serviceable cylinders
Custom OEM hydraulic systems

FAQ

Q: What does CTR3 stand for?
A: CTR3 = Custom Tie-Rod 3000PSI. Tie-rod body with double-lug front clevis and threaded rod end.

Q: Can the CTR3 be serviced in the field?
A: Yes. The tie-rod construction allows complete disassembly for seal replacement without special tools.

Q: Is it double-acting?
A: Yes. All CTR3 cylinders are double-acting.

Q: What are the shipping terms?
A: FOB. Shipping costs, duties, and clearance fees are the buyer's responsibility.
